Product Name:

Salt Spray Test Chambers

Function
  • Use to test the corrosion resistance of the surface of various material after anti-corrosion treatment such as eletroplating, anodizing, spraying, anti-rust oil and so on.
  • Mainly stimulate the impact of maritime climate on product quality and assesses its anti-corrosion ability according to standards.
Product Specification
Chamber Volume 108L 270L 480L 800L 1440L
Inner Size (W*D*H)(cm) 600*400*450 900*500*600 1200*500*800 1600*500*1000 2000*600*1200
Outer size (W*D*H)(cm) 1150*1090*672 1450*1200*842 2080*1258*1240 2480*1520*1450 2900*1550*1650
Salt Water Volume (L) 15 25 40 40 40
Chamber Temp Salt water method (NSS ACSS) 35±1℃ / Corrosion resistance method (CASS) 50±0.1℃
Pressure Tank Temp Salt water method (NSS ACSS) 47±1℃ / Corrosion resistance method (CASS) 63±0.1℃
Saline Concentration Add 0.26g of copper chloride per liter in 5% NaCl solution or 5% CuCl2·2H2O solution
Compressed Air Pressure 1.00±0.01 kgf/cm2
Amount of Spray 1.0-2.0ml/ 80cm2/h, collect at least 16 hrs, take the average
pH Value For NSS ACSS, 6.5-7.2;
For CASS, 3.0-3.2
Spray Method Continuous spray / Optional intermittent spray
Power AC220V1 10A AC220V1 15A AC220V1 20A AC220V1 20A AC220V1 30A
Chamber Volume 8m3 12m3 16m3 Non standard
Studio Size (mm) 2000*2000*2000 3000*2000*200 4000*2000*200 Customized
Chamber Temp NSS ACSS 35±1℃ / CASS 50±0.1℃ / 10℃-70℃ composites
Pressure Tank Temp Salt water method (NSS ACSS) 47±1℃ / Corrosion resistance method (CASS) 63±0.1℃
Humid Range 30-98%RH
Saline Concentration Add 0.26g of copper chloride per liter in 5% NaCl solution or 5% CuCl2·2H2O solution
Compressed Air Pressure 1.00±0.01 kgf/cm2
Amount of Spray 1.0-2.0ml/ 80cm2/h, collect at least 16 hrs, take the average
Lab Relative Humid Above 85%
pH Value For NSS ACSS, 6.5-7.2;
For CASS, 3.0-3.2
Spray Method Continuous spray / Optional intermittent spray
Power AC380V, 3P 28.6kW AC380V, 3P 30.6kW AC380V, 3P 32.6kW Customized
Model 90 120 160 200
Inner Size (W*D*H)(mm) 900*620*600 1200*760*1000 1600*760*1000 2000*760*1100
Outer Size (W*D*H)(cm) 2450*1553*1430 2830*1560*1830 3230*1560*1830 3630*1560*1930
Temp Range RT-70℃ / -10℃-80℃
Humid Range 20-98%RH
Water Spray Pressure 8,000-10,000kPa
T,H Accuracy/Uniformaty 0.1℃; 0.1%RH / ±2.0℃; ±3.0%RH
Chamber Temp NSS ACSS 35±1℃ / CASS 50±0.1
Pressure Tank Temp Salt water method (NSS ACSS) 47±1℃ / Corrosion resistance method (CASS) 63±0.1℃
Brine Temp 35±1℃ 50±1℃
Saline Concentration Add 0.26g of copper chloride per liter in 5% NaCl solution or 5% CuCl2·2H2O solution
Compressed Air Pressure 1.00±0.01 kgf/cm2
Amount of Spray 1.0-2.0ml/ 80cm2/h, collect at least 16 hrs, take the average
Lab Relative Humid Above 85%
pH Value For NSS ACSS, 6.5-7.2;
For CASS, 3.0-3.2
Spray Method Continuous spray / Optional intermittent spray
Power AC380V, 3P 20A AC380V, 3P 23A AC380V, 3P 25A AC380V, 3P 30A
