Product Name:

Temperature and Humidity Test Chambers

100L
150L
225L
408L
800L
1000L
1200L
1400L
1500L
Function
  • Apply in material fields to test functions like heat resistance, cold resistance, dry resistance, and moisture resistance.
Core strength
  • Unique refrigerant servo valve controls flow, energy saving over 30%
  • At 85°C and 85%RH, no need to on the compressor
  • Metering result report
  • Quad-insulation, non-fogging or formation of water droplets
  • Energy saving up to 35%
  • No frost for long-term low temp and humidity condition
Product Specification
Capacity 100L 150L 225L 408L 800L 1000L 1200L 1500L
Inner size (W*D*H)(cm) 50*40*50 50*50*60 70*46*70 70*75*80 100*80*100 100*100*100 150*80*100 150*100*100
Outer size (W*D*H)(cm) 70*125*157 70*135*167 90*157*185 90*188*195 120*185*215 120*295*215 200*135*215 150*100*100
Net weight (kg) 300 360 430 530 780 890 1100 1380
Exterior material Standard 1.5mm electrolytic plate electrostatic spray paint
Interior material Hard urethane foam
Control system PWM control
Temp range Model S: -70℃ to 150℃;
Model L: -40℃ to 180℃;
or customized
Humid range 10%RH to 98%RH
T/H Fluctuation ±0.5℃
T variation in space ±2℃
T pull down rate 1℃/min;
or customized
T heat up rate 3℃/min
Language Chinese / English / Russian
Configuration interface With USB, WLAN, RS232 port, APP function is optional
Power supply AC 220 or AC 110V or AC 380V 50Hz
